For imperial hexagonal head screws
Chrome plated
Chrome Vanadium steel
1000 Volt insulated
5/16 inch
12 point
| Article No. | | Width across
Flats S
Mm | Width across
Flats S
Inch | diameter of effective
Tool side d max.
Mm | Square drive
Inch |
g |
|---|
| 98 37 10 | | 10.0 | | 18.7 | 3/8 | 32 |
| 98 37 11 | 11.0 | | 20.0 | 32 |
| 98 37 12 | 12.0 | | 21.2 | 33 |
| 98 37 13 | 13.0 | | 22.5 | 33 |
| 98 37 14 | 14.0 | | 23.7 | 39 |
| 98 37 16 | 16.0 | | | |
| 98 37 17 | 17.0 | | 27.5 | 61 |
| 98 37 19 | 19.0 | | 30.0 | 73 |
| 98 37 22 | 22.0 | | | |
| 98 37 5/16" | | 5/16 | 16.2 | 30 |
| 98 37 3/8" | | 3/8 | 18.7 | 31 |
| 98 37 7/16" | | 7/16 | 20.0 | 31 |
| 98 37 1/2" | | 1/2 | 22.5 | 33 |
| 98 37 9/16" | | 9/16 | 23.7 | 39 |
| 98 37 5/8" | | 5/8 | 26.2 | 51 |
| 98 37 3/4" | | 3/4 | 30.0 | 71 |
| 98 47 10 | | 10.0 | | 19.5 | 1/2 | 63 |
| 98 47 11 | 11.0 | | 20.7 | 61 |
| 98 47 12 | 12.0 | | 23.0 | 64 |
| 98 47 13 | 13.0 | | 23.2 | 64 |
| 98 47 14 | 14.0 | | 24.5 | 67 |
| 98 47 16 | 16.0 | | 26.9 | 69 |
| 98 47 17 | 17.0 | | 28.2 | 75 |
| 98 47 18 | 18.0 | | 29.0 | 81 |
| 98 47 19 | 19.0 | | 30.7 | 99 |
| 98 47 22 | 22.0 | | 34.5 | 125 |
| 98 47 24 | 24.0 | | 37.0 | 151 |
| 98 47 27 | 27.0 | | 41.0 | 183 |
| 98 47 1/2" | | 1/2 | 23.2 | 67 |
| 98 47 9/16" | | 9/16 | 24.5 | 64 |
| 98 47 5/8" | | 5/8 | 26.9 | 72 |
| 98 47 11/16" | | 11/16 | 28.2 | 88 |
| 98 47 3/4" | | 3/4 | 30.7 | 97 |
| 98 47 7/8" | | 7/8 | 34.5 | 124 |
| 98 47 1" | | 1 | 41.0 | 167 |
NOTE: The product title and description supersede the image(s) shown. The picture provided by the manufacturer is not always exact. We may use the same image for multiple sizes of an item.
Knipex Insulated 5/16" Socket, 3/8" Drive, 12 Point
